MDF330/370/420/520

modular designed digital finishing machine.

label machines

MDF330/370/420/520

modular designed digital finishing machine.

MDF Standard Features
  • All functions are servo motor-controlled
  • Unwind unit with a combined web guide & splice table
  • DUAL MODE Flexo print station - Full & semi-rotary functionality
  • Flexo print to register - print, spot varnish or flood coat
  • Cold foiling in full rotary mode
  • UV or LED ink curing
  • Laminating (Unsupported & supported)
  • DUAL MODE die-cutting station - Rotary & semi-rotary functionality
  • Snowball & standard matrix stripping
  • Rotary shear or crush slitting knives (10 sets)
  • Razor slitting knives (10 sets)
  • Bidirectional dual rewind shafts (76 mm pneumatic)
  • Online remote diagnosis connection to factory.
MDF Optional Extras
  • Web cleaner (Single/dual-sided)
  • Corona treater
  • Semi-rotary cold foiling upgrade
  • Laminate to register (For peel-and-reveal labels)
  • Turn Bar/Delam Relam with turn bar
  • Flat-bed screen printing unit
  • Flat-bed hot foiling/embossing unit
  • Hot air dryer
  • Doming unit
  • Gap Master/Hydra Jacks
  • Robotic auto-slitting setup
  • Back scorers (manual or auto width setup)
  • Semi-turret rewinding unit
  • IML unit (in mould label conveyor and stacking)
  • Alternative diameter pneumatic rewind shafts
MDF Technical Specification

SPECIFICATIONS FOR INDIVIDUAL MDF MODELS

MDF330
Max. Web width
330 mm
MDF370
Max. Web width
370 mm
MDF420
Max. Web width
420 mm
MDF520
Max. Web width
520 mm

SPECIFICATIONS FOR ALL MDF MODELS

Max. Unwind diameter 800 mm
Max. Rewind diameter 600 mm
Die-cutting speed Rotary 0 - 120 m/min
Die-cutting speed Semi-rotary 5 - 60 m/min
Die-cutting accuracy ±0.15 mm
Magnetic Cylinder Size Rotary 70 T – 204 T
Magnetic Cylinder Size Semi-rotary standard 204 T
Max. & Min. die-cutting length in semi-rotary 583 mm - 65 mm
Flexo printing speeds Rotary 0 - 120 m/min
Flexo printing speeds Semi-rotary 0 - 60 m/min
Flexo printing accuracy ±0.15 mm
Flexo plate cylinder size Rotary 60 T – 204 T
Flexo plate cylinder size Semi-rotary standard 204 T
Max. & Min. printing length in semi-rotary (overall repeat length) 583 mm/65 mm
Optional semi-rotary Magnetic cylinder sizes 176 T/192 T

All specifications, dimensions, and construction shown on this website are subject to change without prior notice, this can also mean the look of the machine may alter. If we change anything it's because we're always endeavoring to improve our machines.

IMPORTANT POINT

Our MDF, RDF, and RDR range of systems, combines full and semi-rotary functionality for the die-cutting stations. Dual functionality for flexo printing is included on the MDF range. The desired mode is individually selected from the operator touch screen, giving the perfect choice dependent on the converting and embellishing tasks in hand.

RDF330

Semi + Full Rotary Digital Finishing System.

RDF330

Semi + Full Rotary Digital Finishing System.

RDF Standard Features
  • All functions are servo motor-controlled
  • Unwind unit with a combined web guide & splice table
  • Flexo print to register - print, spot varnish, or flood coat
  • Cold foiling in full rotary mode
  • UV or LED ink curing
  • Laminating (Unsupported & supported)
  • DUAL MODE die-cutting station - Rotary & semi-rotary functionality
  • Servo-controlled matrix stripping
  • Rotary shear or crush slitting knives (10 sets)
  • Razor slitting knives (10 sets)
  • Bidirectional dual rewind shafts (76 mm pneumatic)
  • Online remote diagnosis connection to factory.
RDF Optional Extras
  • Web cleaner (Single/dual-sided)
  • Corona treater
  • Hot air dryer
  • Gap Master/Hydra Jacks
  • Robotic auto-slitting setup
  • Back scorers (manual or auto width setup)
  • Semi-turret rewinding unit
  • IML unit (in mould label conveyor and stacking)
  • Alternative diameter pneumatic rewind shafts
RDF Technical Specification

SPECIFICATIONS FOR ALL MDF MODELS

Max. Web width 330 mm
Max. Unwind diameter 800 mm
Max. Rewind diameter 600 mm
Die-cutting speed Rotary 0 - 120 m/min
Die-cutting speed Semi-rotary 5 - 60 m/min
Die-cutting accuracy ±0.15 mm
Magnetic Cylinder Size Rotary 70 T – 204 T
Magnetic Cylinder Size Semi-rotary standard 204 T
Max. & Min. die-cutting length in semi-rotary 583 mm - 65 mm
Flexo printing speeds 0 - 120 m/min
Flexo printing accuracy ±0.15 mm
Flexo plate cylinder size  60 T – 204 T
Optional semi-rotary Magnetic cylinder size 176 T/192 T
Total power consumption 20kW
Dimensions 3900 mm x 1700 mm x 2000 mm
Weight 2800 kg

IMPORTANT POINT

Our RDF, and RDR range of systems, combines full and semi-rotary functionality for the die-cutting stations. The desired mode is individually selected from the operator touch screen, giving the perfect choice dependent on the converting and embellishing tasks in hand.

RDR330/370/420/520

Semi + Full Rotary Digital Finishing – Mini.

RDR330/370/420/520

Semi + Full Rotary Digital Finishing - Mini.

RDR Standard Features
  • All functions are servo motor-controlled
  • Unwind unit with a combined web guide & splice table
  • Laminating (Unsupported & supported)
  • DUAL MODE die-cutting station - Rotary & semi-rotary functionality
  • Snowball & standard matrix stripping
  • Rotary shear or crush slitting knives (10 sets)
  • Razor slitting knives (10 sets)
  • Bidirectional dual rewind shafts (76 mm pneumatic)
  • Online remote diagnosis connection to factory.
RDR Optional Extras
  • Gap Master/Hydra Jacks
  • Robotic auto-slitting setup
  • Back scorers (manual or auto width setup)
  • Semi-turret rewinding unit
  • IML unit (in mould label conveyor and stacking)
  • Alternative diameter pneumatic rewind shafts.
RDR Technical Specification

SPECIFICATIONS FOR INDIVIDUAL RDR MODELS

RDR330
Max. Web width
330 mm
RDR370
Max. Web width
370 mm
RDR420
Max. Web width
420 mm
RDR520
Max. Web width
520 mm

SPECIFICATIONS FOR ALL RDR MODELS

Max. Unwind diameter 800 mm
Max. Rewind diameter 600 mm
Die-cutting speed Rotary 0 - 120 m/min
Die-cutting speed Semi-rotary 5 - 60 m/min
Die-cutting accuracy ±0.15 mm
Magnetic Cylinder Size Rotary 70 T – 204 T
Magnetic Cylinder Size Semi-rotary standard 204 T
Max. & Min. die-cutting length in semi-rotary 583 mm - 65 mm
Flexo printing speeds Rotary 0 - 120 m/min
Flexo printing speeds Semi-rotary 0 - 60 m/min
Flexo printing accuracy ±0.15 mm
Flexo plate cylinder size Rotary 60 T – 204 T
Flexo plate cylinder size Semi-rotary standard 204 T
Max. & Min. printing length in semi-rotary (overall repeat length) 583 mm/65 mm
Optional semi-rotary Magnetic cylinder sizes 176 T/192 T
Total power consumption 12 kW
Dimensions 3900 mm x 1700 mm x 2000 mm
Weight 2300 kg

All specifications, dimensions, and construction shown on this website are subject to change without prior notice, this can also mean the look of the machine may alter. If we change anything it's because we're always endeavoring to improve our machines.

IMPORTANT POINT

Our RDF, and RDR range of systems, combines full and semi-rotary functionality for the die-cutting stations. The desired mode is individually selected from the operator touch screen, giving the perfect choice dependent on the converting and embellishing tasks in hand.

RD330DA

Digital Plotter Cutting Machine (3 heads).

RD330DA

Digital Cutting Machine (3 heads).

RD330DA Features
  • Simple operation & set up – Auto homing procedure for perfect keyline registration
  • No Die-cutting Tools are required
  • Cuts complex shapes with ease – up to circa 310 mm width x 450 mm length
  • Servo controlled for both cutting & blade height lift/reset
  • Combined web guide & pneumatic splicing table
  • Laminating unit – dual shafts to accommodate both unsupported or supported laminate
  • Servo-controlled sheeting unit with stacking tray - accurately programmable to the required length
  • Independent servo tension control for both unwind & rewind, ensures excellent running stability
  • Simple razor-slitting knives with precise running lateral adjustment
  • Dual pneumatic rewind shafts
  • Online remote diagnosis connection to factory.
RD330DA Technical Specification
Applicable file format .ai .dxf & .pdf
Max. Web width 350 mm
Max. Repeat length 450 mm
Digital blade 3 blades
Laminate 2 shafts
(for unwinding & rewinding)
Cutting speed 0 - 15 m/min (depends on label shape and size)
Cutting accuracy ±0.5 mm
Max. Unwind & rewind roll diameter 400 mm for both
Slitting mode Razor knife slitting (5 knives)
Rewind Dual shafts
Toolset 1 set
Voltage & total power consumption 3PH + N + PE, 380 V, 25.5 A - 12.3 kW
Dimensions  2300 mm x 1300 mm x 1520 mm
Weight 2000 kg

All specifications, dimensions, and construction shown on this website are subject to change without prior notice, this can also mean the look of the machine may alter. If we change anything it's because we're always endeavoring to improve our machines.
